Product Description:
The Pressure Instrument Series is designed with ingress protection (IP) rating of IP68 which means it is dust tight and can withstand continuous immersion in water. This makes it ideal for use in harsh environments where water and dust are present. Furthermore, the series is explosion-proof with an Exd II CT6 rating, making it safe to use in hazardous areas.
The Pressure Instrument Series is available with flange connection for easy installation and reliable performance. The wetted parts material is made of either 304, 316 or PTFE, providing excellent chemical resistance and durability. This ensures that the pressure gauge can withstand harsh chemicals and corrosive environments, making it ideal for use in chemical and petrochemical industries.
In summary, the Pressure Instrument Series is a highly reliable range of pressure gauges suitable for industrial applications. With its wide measurement range, selectable pressure type, ingress protection, explosion-proof rating, flange connection, and durable wetted parts material, it is a great choice for use in harsh and hazardous environments.
Technical Parameters:
| Temperature Compensation Range |
-20°C To 70°C |
| Electrical Connection |
M20*1.5 |
| Explosion-proof Rating |
Exd II CT6 |
| Wetted Parts Material |
304, 316 Or PTFE |
| Ingress Protection (IP) Rating |
IP68 |
| Accuracy Class |
±0.25% FS, ±0.5% FS (Selectable) |
| Long-term Stability |
≤±0.2% FS/year |
| Supply Voltage |
12-36V DC |
| Pressure Type |
Gauge Pressure, Absolute Pressure(Selectable) |
| Output Signal |
4-20mA,0-5V,0-10V,RS485 |
| Linearity |
±0.25% FS |
| Process Connection |
M20*1.5 |
| Flange Connection |
N/A |
Applications:
The DX-132P Pressure Instrument Series has a measurement range of 0kPa to +60MPa, which is selectable based on your needs. It also has an overload pressure of 2 times full-scale pressure, ensuring durability and accuracy. Operating temperature range is -40°C to 85°C, making it suitable for use in different environments. Its explosion-proof rating is Exd II CT6, making it safe for use in hazardous locations.
One of the standout features of this product is its Ingress Protection (IP) Rating of IP68, making it dust-tight and waterproof. This makes it ideal for use in harsh environments, including those with exposure to water and other liquids. The product is made of high-quality materials to ensure its longevity and durability, and it is suitable for use in a variety of applications.
Oil and gas industries often require pressure instruments for monitoring, control, and safety purposes. The DX-132P Pressure Instrument Series is well-suited for use in these industries, as well as in other applications where pressure measurement is necessary. Its accuracy, durability, and safety features make it a reliable choice for professionals.
Support and Services:
Our Pressure Instrument Series product comes with comprehensive technical support and services to ensure that you get the most out of your purchase. Our experienced technicians are available to assist you with any troubleshooting, calibration, or repair needs you may have. Our services include:
- 24/7 technical support hotline
- Onsite calibration and repair services
- Training and education programs
- Customized maintenance plans
- Extended warranty options
We are committed to providing you with the highest level of support and service to ensure that your Pressure Instrument Series product meets your needs and expectations.
