Product Description:
The Pressure Instrument Series features a temperature compensation range of -10°C to 60°C, ensuring accurate readings even in challenging environments. It also has an operating temperature range of -40°C to 85°C, making it suitable for use in a variety of conditions.
Designed for accuracy, the Pressure Instrument Series has an accuracy class of ±0.25% FS or ±0.5% FS (selectable), ensuring precise measurements every time. The device is available with a threaded connection, which makes it easy to install and use.
The Pressure Instrument Series is available with wetted parts material options of 304, 316, or PTFE, depending on your specific requirements. This ensures that the device is compatible with a wide range of fluids and gases.
In addition, the Pressure Instrument Series has an ingress protection rating, which ensures that it is protected from dust and water. It also has a supply voltage of 12-36 VDC, making it easy to power and integrate into your existing systems.
Technical Parameters:
| Temperature Compensation Range |
-10°C To 60°C |
| Wetted Parts Material |
304, 316 Or PTFE |
| Operating Temperature Range |
-40°C To 85°C |
| Accuracy Class |
±0.25% FS, ±0.5% FS (Selectable) |
| Long-term Stability |
≤±0.25% FS/year |
| Supply Voltage |
12-36V DC |
| Overload Pressure |
2 Times Full-scale Pressure |
| Pressure Type |
Gauge Pressure |
| Output Signal |
4-20mA,0-5V,0-10V,RS485 |
| Ingress Protection (IP) Rating |
IP65 |
This Pressure Instrument Series product is a Pressure Transmitter that offers a Pressure Measurement Range of 2 Times Full-scale Pressure. It features a durable Process Connection and is compatible with a variety of Wetted Parts Materials including 304, 316 or PTFE. The device has an Accuracy Class of ±0.25% FS, ±0.5% FS (Selectable) and a Long-term Stability of ≤±0.25% FS/year. It is designed to operate within a Temperature Compensation Range of -10°C To 60°C and an Operating Temperature Range of -40°C To 85°C. The device can be powered by a Supply Voltage of 12-36V DC and features an Overload Pressure of 2 Times Full-scale Pressure. It is a Gauge Pressure type device and offers Output Signal options of 4-20mA,0-5V,0-10V,RS485. It has an Ingress Protection (IP) Rating of IP65.
Applications:
The DX-131P Pressure Instrument Series from Wuxi Daoxin Technology Co., Ltd. is a high-quality and reliable pressure measuring tool suitable for a wide range of applications. This product comes with a range of features and attributes that make it ideal for use in various scenarios.
Product Application Occasions
The DX-131P Pressure Instrument Series is designed to be used in a variety of industrial applications, including:
- Oil and gas industry
- Chemical industry
- Water treatment plants
- Food and beverage industry
- Pharmaceutical industry
Scenarios
Here are some of the specific scenarios where the DX-131P Pressure Instrument Series can be used:
- Monitoring pressure in pipelines
- Measuring pressure in tanks and vessels
- Ensuring pressure consistency in manufacturing processes
- Monitoring pressure in HVAC systems
- Measuring pressure in hydraulic and pneumatic systems
Support and Services:
The Pressure Instrument Series product technical support and services include:
- Assistance with installation, setup, and configuration
- Troubleshooting and diagnosis of technical issues
- Repairs and maintenance services
- Calibration and certification services
- Product training and education
- Access to online resources and documentation
